Features
- Complies with the latest HDMI/HDCP 2.2 standard to enable full spec 4K signal input with 18Gbps transmission band-width (4K60P 4:4:4, 4K60P 4:2:2/36-bit, 4K24P 4:4:4/36-bit)
- Light source: NSH 265 W lamp
- Resolution: 8192 x 4320 (with 8K/e-shift)
- Input connectors: HDMI x 2 (3D, Deep Color/HDCP 2.2)
- Output and control connectors: RS-232C (D-sub 9pin) x 1, LAN (RJ-45) x 1, Trigger x 1 (Mini jack), 3D Sync x 1 (Mini-DIN 3pin)
- 3D formats: Frame Packing, Side-by-Side (Half), and Top and Bottom
- JVCs proprietary 8K/e-shift technology reproduces image quality beyond 4K** (The projector does not support 8K signal input)
- New 0.69-inch 4K D-ILA (4096 x 2160) device x 3
- 18-element, 16-group all-glass 100mm diameter high-quality lens
- Multiple Pixel Control image processor accurately reproduces images closer to the original
- High brightness of 2,200 lm provides vibrant and dynamic imagery
- Native Contrast Ratio of 100,000:1 translates to a spectacular Dynamic Contrast Ratio of 1,000,000:1
- Wide Color Gamut above exceeds DCI/P3 spec creating saturated, beautiful images that come to life
- Compatible with HDR technology that dramatically improves image quality that rivals real life.
- Auto Tone Mapping function automatically adjusts settings for optimum HDR10 image quality
- For easy reproduction, the projector switches automatically to HDR picture mode when HDR10 signals are received
- Display the MaxCLL and MaxFALL mastering data available for HDR content on some UHD Blu-ray discs
- Compatible with Hybrid Log-Gamma that is expected to be used widely in future broadcasting
- Installation Mode centrally manage nine settings related to installation to enjoy video best suited for each environment
- Nine settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, Pincushion, and Aspect; stored installation modes for various environments can be called up.
- Renewed Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever
- Motion Enhance technology reduces residual images and blurring that are often found in fast-moving images by optimally controlling the drive of D-ILA devices
- Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles
- Color Management System with 6-axis Matrix
- Auto-Calibration Function using an optical sensor* is capable of optimizing essential elements in the image, including color balance, gamma characteristics, color space and color tracking
- THX 4K Display Certification to ensure the precise reproduction of picture quality in 4K content, just as the original filmmaker envisioned.
- ISF C3 (Certified Calibration Controls) mode** to reproduce excellent picture quality optimized for specific environments.
- Wireless transmission options for 3D viewing: RF (radio frequency) system transmission with PK-AG3 3D Glasses for 100H continuous operation and PK-EM2 3D Synchro Emitter
- *Exclusive JVC software installed in PC and optical sensor are required. Please visit the JVC website for details. **Professional calibration to desired screen is performed by trained dealers
| Device | 0.69-inch Native 4K DILA Device (4096×2160) x3 |
| e-shift Technology | Yes |
| Resolution | 8192 x 4320 (with 8K e-shift) |
| Lens shift function | +/-100% vertical & +/-43% horizontal, motorized in 16:9 aspect mode |
| Light source lamp | NSH 265 W |
| Lamp life | Approx. 4500 hours in Low mode |
| Brightness | 2,200 lm |
| Contrast Ratio | Native: 100,000:1, Dynamic: 1,000,000:1 |
| Power requirement | AC100V-240V, 50/60Hz |
| Dimensions: W x H x D, mm | 500 x 234 x 518 |
| Dimensions: W x H x D, inches | 19-3/4 x 9-1/4 x 20-1/2 |
| Weight, kg | 21.8 |
