PRODUCT SPECIFICATION
| Brand & Model |
Denon PMA-900HNE Amplifier |
| Power Amplifier Section |
- Output power 8 Ohm (20 Hz – 20 kHz, T.H.D. 0.07%): 50W + 50W
- Output power 4 Ohm (1 kHz, T.H.D. 0.7%): 85W + 85W
- Total Harmonic Distortion: 0.01% (-3dB, 8ohm, 1kHz)
- Power Amplifier Circuit: Advanced HC Single Push-Pull Circuit
- Power Amp Output circuit Structure: Single Push-Pull with Darlington transistor
- Pre Amplifier Circuit: Variable Gain Preamplifier
- Volume: Electric – Controlled by Encoder
- Bass Treble Mid Balance Control: Yes / Yes / No / Yes
- Source Direct: Yes
- Input Sensitivity: MM: 2.5mV / 47 kohm
- Input Sensitivity: MC: 200
- Signal to Noise Ratio: MM/MC: 86 dB / 71 dB
- Input Sensitivity: High level: 105 mV / 40kohms (Source Direct Off)
- Signal to Noise Ratio: High level: 105dB
- Treble Control: ± 8 dB at 10 kHz
- Bass Control: ± 8 dB at 100 Hz
|
| Features |
- Advanced HC-TR single push pull circuit: Yes
- Wide range amplifier: Yes
- High current dynamic power supply: Yes
- Power amp discrete construction: Yes
- Micro processor auto off: Yes
- Solid Heat Sinks: Yes
- Wi-Fi / Wired LAN: Yes / Yes
- Wi-Fi: 2.4GHz (11b/g/n) 5GHz (11a/n/ac)
- Wi-Fi Off Mode: Yes
- Bluetooth / aptX / NFC: Yes / No / No
- Internet Radio: Yes (TuneIn)
- Pandora: Yes (NA)
- Sirius XM Internet Radio: Yes (NA)
- Spotify Connect :Yes
- Deezer Premium+ / Deezer HiFi: Yes / No (NA / EU)
- QQ MUSIC: Yes (China)
- Sound Cloud: Yes
- Tidal: Yes (NA / EU)
- Amazon Music Unlimited / Amazon Music HD / Prime Music: Yes / Yes / Yes
- Napster: Yes
- iHeartRadio: Yes (NA)
- Mood Mix: Yes (NA / EU)
- AWA: Yes(Japan)
- Other: Yes
- Airplay: Yes (Airplay 2)
- DSD-Audio network streaming: Yes (5.6Mhz)
- Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
- Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF: Yes / Yes / Yes / Yes / No
- Gapless Playback: Yes
- Remote APP: iDevice / Android: Yes / Yes
- Sample Rate digital In: 192 kHz / 24-bit
- USB-A: DSD / WAV / FLAC / AIFF / ALAC: <=5.6 / 192 / 192 / No / 96
- Works with Amazon Alexa: Yes
- Works with Google Assistant: Yes
- Works with Apple AirPlay (Siri): Yes
|
| Others |
- Low Noise OELD display: Yes
- Source Direct: Yes
- Display: Dimmer / Off: Yes / Yes
- IR Learning for TV: Yes
|
| Inputs / Outputs |
- Audio Inputs: RC-1246
- Digital in: USB-B / optical / coaxial / USB-A: 0 / 3 / 1 / 1
- Phono Input: MM / MC: Yes / Yes
- Audio Outputs
- Pre-out / Main-in: Subwoofer / No
- Power Amp Direct IN: No
- Gold plated Cinch: Yes
- Speaker A / B: Yes
- Remote Control Bus in / out: Yes (Remote Out)
- Headphone Out Yes
- Headphone Gain Control (low / mid / high) No
|
| General |
- Metal Front Panel: Aluminum
- Power Consumption in W: 200W
- Standby Consumption in W: 0.2W
- Auto Power Off: Yes
- Detachable Power Cable: Yes
- Remote Control: RC-1246
- System Remote Function: Yes
- Maximum Dimensions (W x D x H): 434 x 376 x 131mm / 17.1 x 14.8 x 5.2in
- Weight 8.3kg / 18.3lb
|
PRODUCT DESCRIPTION
KEY FEATURES
2-Channel Configuration
50W per Channel Power Output @ 8 ohms
Wi-Fi, Ethernet, Bluetooth, and HEOS
Works with Alexa, Siri, Google & Josh.ai
3 x Optical & 1 x Digital Coaxial Inputs
3 x Stereo RCA & 1 x Phono Input
Stereo RCA Output
Hi-Res Audio Support
Front OLED Info Display
Play hi-res audio from your analog, digital, and streaming sources with the Denon PMA-900HNE 100W Integrated Network Amplifier. Utilizing high-grade audio components, a vibration-resistant design, and a high current output, the PMA-900HNE is able to drive 50W per channel at 8 ohms to your existing loudspeakers with minimal noise. In addition to analog and digital inputs, this amplifier provides a dedicated USB Type-A port, a phono input for direct turntable connection, and HEOS Built-In for wireless access to a nearly limitless digital library. You can connect to your network via Wi-Fi or wired LAN, or stream via Bluetooth or AirPlay 2 from a mobile device.
VOICE CONTROL
This network amplifier supports Amazon Alexa, Google Assistant, Apple Siri, and Josh.ai for convenient voice control over media access and playback.
HI-RES AUDIO
Whether through your network, external drive, or mobile device, the PMA-900HNE is capable of playing a variety of Hi-Res Audio codecs. It supports ALAC, FLAC, and WAV lossless up to 24-bit/192 kHz, in addition to DSD at 2.8 and 5.6 MHz.
ADDITIONAL FEATURES
Built-in phono equalizer for turntables with MM cartridges
Roon Tested
Headphone output
Front control knobs for volume, input selection, bass, treble, and balance
Front OLED info display
Auto power off
WHAT’S IN THE BOX:
Integrated amplifier
68″ AC power cord
Remote control (RC-1246)
Two “AAA” batteries
2 WiFi/Bluetooth antennas
uick Start Guide
Spotify Connect Instructions
Heos Brochure
Safety Instructions
Notes on Radio
Warranty Information
Bluetooth/WiFi antenna note
WARRANTY : 1-year manufacturer’s warranty
